Sbend Series
Sbend series coaxial cable is a super flexible phase stable cable. It is built with flexible material with rational design. Meanwhile, it has good phase stability. Attenuation and VSWR won’t fluctuate rapidly while bending. It is applied to special application condition like narrow space or frequent bending.
Product Structure
Center Conductor Silver plated copper
Dielectric Solid PTFE
Outer Conductor Silver plated copper
Outer shield Silver plated copper
Outer Jacket Orange FEP
Inner Layer PET/PTFE
Features and Advantages
  • Up to 40GHz
  • Low loss
  • Excellent flexibility
  • Good mechanical phase stability
Typical Applications
  • Satellite communication
  • Feed network
  • Board to Board connection
