Application
- 1.The network system
- 2. Meter and instrument
- 3. Telephone communication system
- 4. National defence or aerospace applications
| Electrical Performance | |
|---|---|
| Impedance | 50 Ohm |
| Frequency range | DC-2.5 GHz |
| Operating voltage | 830 V(rms) |
| Dielectric Withstanding Voltage | 2500 V(rms) |
| Conductor resistance | Inner conductor: ≤5.0 mΩ (initial value) |
| Outer conductor: ≤3.0 mΩ (initial value) | |
| Insulation resistance | ≥5000 mΩ |
| VSWR | Straight: ≤1.30 (typical value) |
| Right angle: ≤1.35 (typical value) | |
| Mechanical Characteristics | |
|---|---|
| Nut pull force | ≥80 lbs |
| Nut torque | ≥15 inch lbs |
| Center pin retention | ≥6 lbs |
| Durability | >500 times |
